Terminal-Based Text Editor

Source Code available at: github.com/akshatddyl/terminal-based-text-editor

Most text editors hide their buffer implementation behind a language runtime and a UI framework. I wanted to see what's actually underneath: build the buffer, the undo system, the autocomplete, and the syntax highlighter myself, in C, with nothing but ncurses for rendering — and find out exactly where a "smarter" data structure actually earns its complexity, versus where it doesn't.

Tech Stack

Architecture & Implementation

The buffer is a rope: a binary tree of leaf nodes (capped at 32 characters each) where every internal node caches the total length, newline count, and depth of its left subtree. That caching is what makes line/column lookups — "where's line 40," "what column is the cursor on" — an O(log n) tree descent instead of a linear scan through the whole file, which matters constantly during normal editing, not just for the insert/delete path. Every mutation — insert, delete, split, concatenate — is followed by a recursive invariant check (validate_rope) that walks the tree and asserts its cached weights, lengths, and newline counts are still internally consistent, so a corrupted tree fails loudly at the exact operation that broke it instead of surfacing as a mysterious crash three edits later.

Undo/redo deliberately isn't built on the rope's own structure — it's a separate ring-buffer stack of Operation records, each storing the exact position, text, and operation type (OP_INSERT/OP_DELETE) needed to invert it. The stack caps at 100 entries and drops the oldest on overflow, trading unlimited undo history for a hard memory ceiling.

Search and replace runs Boyer-Moore's bad-character heuristic directly against the rope through rope_char_at(), rather than flattening the buffer into a plain string first — each individual character comparison costs O(log n) to descend the tree, which the code's own comment calls out explicitly, on the reasoning that Boyer-Moore's skip-ahead nature keeps the total number of character comparisons low enough that the per-comparison cost doesn't dominate in practice.

Auto-suggestion and syntax highlighting both run on every keystroke: the current word's prefix is queried against a trie for an O(m) completion, and each parsed token is hashed against a 128-bucket table mapping keywords straight to their ncurses color pair for the render loop. Crash recovery works at two levels — every meaningful edit triggers a background write to a hidden .swp file, and an explicit save writes to a .tmp file first and only rename()s it over the real file afterward, which is atomic on POSIX filesystems, so a crash mid-save can never leave a half-written file behind.

Challenges & Trade-offs

The most interesting result in the whole project is one that doesn't flatter the rope: a dedicated benchmark of 100,000 random insertions and deletions at the buffer's midpoint showed the naive flat-array buffer finishing in ~0.045s against the rope's ~1.479s — the "worse" data structure won, by a lot. That's not a bug, it's a real crossover point: at buffer sizes small enough to stay cache-resident, memmove's raw throughput and CPU vectorization beat a tree of individually heap-allocated, pointer-chasing nodes, and the rope's O(log n) advantage only starts paying for itself once files get large enough that O(n) memmove genuinely dominates. Reporting that honestly — instead of only showing the asymptotic argument — was the right call, and it's the kind of result that only shows up when you actually benchmark instead of trusting Big-O intuition.

The recursive invariant validation after every rope mutation is its own deliberate trade: extra tree traversals on every insert and delete, in exchange for turning silent structural corruption into an immediate, localized assert() failure during development. And the Boyer-Moore search's O(log n)-per-character cost against the tree, instead of against a flat buffer, was an accepted trade rather than an oversight — a buffered iterator would be faster, but for an editor's search workload the skip-ahead heuristic already limits how often characters get compared, so the added complexity wasn't judged worth it.

What I Learned

• Learned that asymptotic complexity isn't the same as real-world speed — an O(log n) structure can genuinely lose to an O(n) one at realistic sizes, and only benchmarking, not Big-O intuition alone, reveals where the actual crossover point is.
• Learned to treat a data structure's invariants as testable, enforced properties rather than assumptions — recursive validation after every mutation turns silent memory corruption into an immediate, localized failure instead of a mystery three operations later.
• Gained hands-on memory-safety discipline in C: building and debugging pointer-heavy structures (rope, trie, hash table) under Valgrind until they were provably leak-free and segfault-free under sustained stress.
